The A Series is a Submersible Electric Pump featuring an Open Channel Impeller. This high-quality submersible pump is used for pumping & draining clear liquids & sewage. A Series open channel impeller pumps are ideal for wastewater treatment plants, industrial plants, farms and sewers.

Submersible Electric Pumps with Open Channel Impeller

Submersible Pump Features:

  • Main components fabricated in cast iron GG25
  • Electric powered, available in 60Hz, 3-phase, 460 V options
  • 2-pole or 4-pole options available
  • Fitted with open single channel impellers
  • Seal Minder Probe® standard on all models

Pump Applications:

  • Pumping & draining clear liquids
  • Sewage pumping & drainage
  • Wastewater treatment plants
  • Industrial plants
  • Farms & other agricultural properties
  • Sewers
Let Us Help Design Your System

Literature

Brochure
Operation Manual
Dimensions
ModelDatasheet & CurvesMotor RatingVoltagePhase FrequencyFull Load AmpsDischargeWeightMax HeadMax FlowMax Solids
a2-19 Download IFS-BJM-A2-19-datasheet-and-curve-09.16.2024.pdf 1.9kW (2.5HP)4603ph-60Hz4.1DN65-PN1041kg (90lbs)15.2m (50ft)195 GPM40mm (1.6in)
A2-22 Download IFS-BJM-A2-22-datasheet-and-curve-09.16.2024.pdf 2.2kW (3HP)4603ph-60Hz4.8DN65-PN1042kg (92lbs)24.7m (81ft)262 GPM40mm (1.6in)
A2-41 Download IFS-BJM-A2-41-datasheet-and-curve-09.16.2024.pdf 4.1kW (5.5HP)4603ph-60Hz8.3DN80-PN1660kg (132lbs)25.3m (83ft)325 GPM45mm (1.75in)
A2-56 Download IFS-BJM-A2-56-datasheet-and-curve-09.16.2024.pdf 5.6kW (7.5HP)4603ph-60Hz11DN80-PN1670kg (154lbs)33.5m (110ft)392 GPM60mm (2.4in)
A2-75 Download IFS-BJM-A2-75-datasheet-and-curve-09.16.2024.pdf 7.5kW (10HP)4603ph-60Hz14DN80-PN1670kg (154lbs)40.8m (134ft)472 GPM60mm (2.4in)
A2-97 Download IFS-BJM-A2-97-datasheet-and-curve-09.16.2024.pdf 9.7kW (13HP)4603ph-60Hz18.2DN80-PN1670kg (154lbs)47.5m (156ft)545 GPM65mm (2.6in)
A4-15 Download IFS-BJM-A4-15-datasheet-and-curve-09.16.2024.pdf 1.5kW (2HP)4603ph-60Hz3.4DN80-PN1656kg (124lbs)10.1m (33ft)344 GPM75mm (3in)
A4-22 Download IFS-BJM-A4-22-datasheet-curve-03.2025-DS-C43-013.pdf 2.2kW (3HP)4603ph-60Hz4.8DN80-PN1669kg (152lbs)11.9m (39ft)377 GPM75mm (3in)
A4-30 Download IFS-BJM-A4-30-datasheet-and-curve-09.16.2024.pdf 3kW (4HP)4603ph-60Hz6.2DN80-PN1693kg (205lbs)16.5m (54ft)436 GPM75mm (3in)
A4-41 Download IFS-BJM-A4-41-datasheet-and-curve-09.16.2024.pdf 4.1kW (5.5HP)4603ph-60Hz8.3DN100-PN16103kg (227lbs)18.9m (62ft)716 GPM90mm (3.5in)
A4-56 Download IFS-BJM-A4-56-datasheet-and-curve-09.16.2024.pdf 5.6kW (7.5HP)4603ph-60Hz11DN100-PN16108kg (238lbs)20.1m (66ft)819 GPM90mm (3.5in)
A4-75 Download IFS-BJM-A4-75-datasheet-and-curve-09.16.2024.pdf 7.5kW (10HP)4603ph-60Hz14DN100-PN16110kg (243lbs)24.1m (79ft)944 GPM90mm (3.5in)
