RX Series
- Portable, corrosion-resistant dewatering pump
- Top discharge pass liquids around motor for cooling
- Cast 316 stainless steel (ASTM 48), no welds
- FKM Elastomers (EPDM or Buna Optional)
- Thermal overload protection
- Class F motor insulation
- 3-phase unit suitable for VFD use
- 1HP – 2HP motor
| Model | Datasheet & Curves | Motor Rating | Voltage | Phase Frequency | Full Load Amps | Discharge | Weight | Max Head | Max Flow | Max Solids |
|---|---|---|---|---|---|---|---|---|---|---|
| R750SS |
Download IFS-BJM-RX750SS-datasheet.pdf
| 1hp | 115/230 | 1ph-60Hz | 14/7 | 2" NPT-M | 64 lbs | 49' | 116 GPM | 1/4" |
| RX08SS |
Download IFS-BJM-RX08SS-datasheet.pdf
| 2hp | 208/230/460/575 | 3ph-60Hz | 3.5/3.2/1.6/1.3 | 2" NPT-M | 68lbs | 71' | 89 GPM | 1/4" |
| RX15SS |
Download IFS-BJM-RX15SS-datasheet.pdf
| 2hp | 208/230/460/575 | 3ph-60Hz | 6.6/6/3/2.3 | 2" NPT-M | 70 lbs | 71' | 116 GPM | 1/4" |
| RX1500SS |
Download IFS-BJM-RX1500SS-datasheet.pdf
| 2hp | 115/230, 208/230/460/575 | 1ph-60Hz | 14 | 2" NPT-M | 80 lbs | 71' | 116 GPM | 1/4" |
