SK Series BJM Pump

Solids-Handling, Non-Clog, Shredder Pump

  • Solids-Handling, Non-Clog, Shredder Pump
  • Wear-resistant shredding and cutting system designed to tear, break, rip solids
  • Tungsten carbide-tipped impeller
  • Max solids from 1.6-3.5 inches
  • Motor housing: 304 stainless steel
  • High chrome suction plate
  • Dual mechanical seals
  • Seal Minder® moisture detection system
  • ANSI or NPT discharge flange
  • Integrated, removable pump stand
  • 33’ power and Seal Minder Cable
  • Heavy duty lifting rings
  • Built-in thermal protection
  • Class H motor insulation
  • 2-pole and 4-pole motors available
  • Single-phase and 3-phase voltages
  • 1HP – 20HP
  • Free-standing and guide-rail mounted compatibility
Let Us Help Design Your System

Literature

Brochure
Dimensions
Specifications
Parts Lists/Exploded Views
Operation Manual
ModelDatasheet & CurvesMotor RatingVoltagePhase FrequencyFull Load AmpsDischargeWeightMax HeadMax FlowMax Solids
SK08C Download IFS-BJM-SK08C-datasheet.pdf 1hp208/230/460/5753ph-60Hz3.5/3/1.6/1.32" NPT-M68 lbs48'95 GPM2"
SK1500C Download IFS-BJM-SK1500C-datasheet.pdf 2hp2301ph-60Hz143" NPT-M100 lbs45'220 GPM1.6"
SK15C Download IFS-BJM-SK15C-datasheet.pdf 2hp208/230/460/5753ph-60Hz6.3/6/3/2.33" NPT-M89 lbs45'220 GPM1.6"
SK22C Download IFS-BJM-SK22C-datasheet.pdf 3hp208/230/460/5753ph-60Hz9.45/9/4.5/3.23" NPT-M123 lbs51'270 GPM1.6"
SK37C Download IFS-BJM-SK37C-datasheet.pdf 5hp208/230/460/5753ph-60Hz14.7/14/7/5.53" Flange w/ 4" NPT-F discharge (3" NPT-M optional)130 lbs69'360 GPM1.6"
SK55C Download IFS-BJM-SK55C-datasheet.pdf 7.5hp230/460/5753ph-60Hz21/10.5/7.84" NPT-F380 lbs54'570 GPM3.5"
SK75C Download IFS-BJM-SK75C-datasheet.pdf 10hp460/5753ph-60Hz15/10.54" NPT-F395 lbs64'670 GPM3.5"
SK110C Download IFS-BJM-SK110C-datasheet.pdf 15hp460/5753ph-60Hz19.8/13.76" FLANGE, ANSI605 lbs94'845 GPM3.5"
SK150C Download IFS-BJM-SK150C-datasheet.pdf 20HP460/5753ph-60Hz25.7/19.86" FLANGE, ANSI630 lbs101'911 GPM3.5"
