High Temperature Shredder Pump
- Fahrenheit® High Temperature Shredder Pump
- Withstands temperatures up to 200°F (93°C)
- Wear-resistant shredding system
- Heavy duty lifting rings
- Built in thermal protection
- Cable entry sealing system to prevent wicking
- ANSI For NPT discharge flange
- Seal Minder® moisture detection system
- Class F motor insulation
- Integral pump stand
| Model | Datasheet & Curves | Motor Rating | Voltage | Phase Frequency | Full Load Amps | Discharge | Weight | Max Head | Max Flow | Max Solids |
|---|---|---|---|---|---|---|---|---|---|---|
| SK08CF |
Download IFS-BJM-DatasheetCurve-DS-C26-005-SK08F-Technical-Datasheet-Rev-2111525.pdf
| 1HP (0.7kW) | 208/230/460/575 | 3ph-60Hz | 3.5/3/1.6/1.3 | 2" NPT-M | 68lbs (30.8kg) | 50ft (15.2m) | 88GPM (333LPM) | 2in (51mm) |
| SK15CF |
Download IFS-BJM-DatasheetCurve-DS-C26-009-SK15CF-Technical-Datasheet-Rev-1111525.pdf
| 2HP (1.5kW) | 208/230/460/575 | 3ph-60Hz | 6.3/6/3/2.3 | 3" NPT-M | 110lbs (49.9kg) | 43ft (13.1m) | 255GPM (965LPM) | 1.6in (41mm) |
| SK1500CF |
Download IFS-BJM-DatasheetCurve-DS-C26-015-SK1500CF-Technical-Datasheet-Rev-1111525.pdf
| 2HP (1.5kW) | 230 | 3ph-60Hz | 16 | 3" NPT-M | 89lbs (40.4kg) | 42ft (12.8m) | 226GPM (856LPM) | 1.6in (41mm) |
| SK22CF |
Download IFS-BJM-DatasheetCurve-DS-C26-010-SK22CF-Technical-Datasheet-Rev-1111525.pdf
| 3HP (2.2kW) | 208/230/460/575 | 3ph-60Hz | 9.45/9/4.5/3.2 | 3" NPT-M | 130lbs (59kg) | 51ft (15.5m) | 290GPM (1098LPM) | 1.6in (41mm) |
| SK37CF |
Download IFS-BJM-DatasheetCurve-DS-C26-011-SK37CF-Technical-Datasheet-Rev-1111525.pdf
| 5HP (3.7kW) | 208/230/460/575 | 3ph-60Hz | 14.7/14/7/5.5 | 3" FLANGE W/ 4" NPT-F DISCHARGE | 133lbs (60.3kg) | 71ft (21.6m) | 334GPM (1264LPM) | 1.6in (41mm) |
| SK55CF |
Download IFS-BJM-DatasheetCurve-DS-C26-012-SK55CF-Technical-Datasheet-Rev-1111525.pdf
| 7.5HP (5.6kW) | 230/460/575 | 3ph-60Hz | 21/10.5/7.8 | 4" NPT-F | 381lbs (172.8kg) | 51ft (15.5m) | 611GPM (2313LPM) | 3.5in (89mm) |
| SK75CF |
Download IFS-BJM-DatasheetCurve-DS-C26-013-SK75CF-Technical-Datasheet-Rev-1111525.pdf
| 10HP (7.5kW) | 460/575 | 3ph-60Hz | 15/10.5 | 4" NPT-F | 396lbs (179.6kg) | 63ft (19.2m) | 702GPM (2657LPM) | 3.5in (89mm) |
| SK110CF |
Download IFS-BJM-DatasheetCurve-DS-C26-017-SK110CF-Technical-Datasheet-Rev-1111525.pdf
| 10HP (7.5kW) | 460/575 | 3ph-60Hz | 19.8/13.7 | 6" FLANGE, ANSI | 606lbs (274.9kg) | 90ft (27.4m) | 787GPM (2979LPM) | 3.5in (89mm) |
| SK150CF |
Download IFS-BJM-DatasheetCurve-DS-C26-008-SK150CF-Technical-Datasheet-Rev-1111525.pdf
| 20HP (14.9kW) | 460/575 | 3ph-60Hz | 25.7/19.8 | 6" FLANGE, ANSI | 631lbs (286.2kg) | 105ft (32m) | 874GPM (3308LPM) | 3.5in (89mm) |
